MapReduce

A framework for large-scale parallel processing

Paul Krzyzanowski

November 2011

Introduction

Traditional programming tends to be serial in design and execution. We tackle many problems with a sequential, stepwise approach and this is reflected in the corresponding program. With parallel programming, we break up the processing workload into multiple parts, that can be executed concurrently on multiple processors. Not all problems can be parallelized. The challenge is to identify as many tasks as possible that can run concurrently. Alternatively, we can identify data groups that can be processed concurrently. This will allow us to divide the data among multiple concurrent tasks.

The most straightforward situation that lends itself to parallel programming is one where there is no dependency among data. Data can be split into chunks and each process can be assigned a chunk to work on. If we have lots of processors, we can split the data into lots of chunks. A master/worker approach is a design where a master process coordinates overall activity. It identifies the data, splits it up based on the number of available workers, and assigns a data segment to each worker. A worker receives the data segment from the master, performs whatever processing is needed on the data, and then sends results to the master. At the end, the master does whatever final processing (e.g., merging) is needed to the resultant data.

MapReduce Etymology

MapReduce is was created at Google in 2004 by Jeffrey Dean and Sanjay Ghemawat. The name is inspired from map and reduce functions in the LISP programming language. In LISP, the map function takes as parameters a function and a set of values. That function is then applied to each of the values. For example:

(map ‘length ‘(() (a) (ab) (abc)))

applies the length funciton to each of the three items in the list. Since length returns the length of an item, the result of map is a list containing the length of each item:

(0 1 2 3)

The reduce function is given a binary function and a set of values as parameters. It combines all the values together using the binary function. If we use the + (add) function to reduce the list (0 1 2 3):

(reduce #'+ '(0 1 2 3))

we get:

6

If we think about how the map operation, we realize that each application of the function to a value can be performed in parallel (concurrently) since there is no dependence of one upon another. The reduce operation can take place only after the map is complete.

MapReduce is not an implementation of these LISP functions; they are merely an inspiration and etymological predecessor.

MapReduce

MapReduce is a framework for parallel computing. Programmers get a simple API and do not have to deal with issues of parallelization, remote execution, data distribution, load balancing, or fault tolerance. The framework makes it easy for one to use thousands of processors to process huge amounts of data (e.g., terabytes and petabytes).

From a user's perspective, there are two basic operations in MapReduce: Map and Reduce.

The Map function reads a stream of data and parses it into intermediate (key, value) pairs. When that is complete, the Reduce function is called once for each unique key that was generated by Map and is given the key and a list of all values that were generated for that key as a parameter. The keys are presented in sorted order.

As an example of using MapReduce, consider the task of counting the number of occurrences of each word in a large collection of documents. The user-written Map function reads the document data and parses out the words. For each word, it writes the (key, value) pair of (word, 1). That is, the word is treated as the key and the associated value of 1 means that we saw the word once. This intermediate data is then sorted by MapReduce by keys and the user's Reduce function is called for each unique key. Since the only values are the count of 1, Reduce is called with a list of a "1" for each occurence of the word that was parsed from the document. The function simply adds them up to generate a total word count for that word. Here's what the code looks like:

map(String key, String value): // key: document name, value: document contents for each word w in value: EmitIntermediate(w, "1"); reduce(String key, Iterator values): // key: a word; values: a list of counts int result = 0; for each v in values: result += ParseInt(v); Emit(AsString(result));

Let us now look at what happens in greater detail.

MapReduce: More Detail

To the programmer, MapReduce is largely seen as an API: communication with the various machines that play a part in execution is hidden. MapReduce is implemented in a master/worker configuration, with one master serving as the coordinator of many workers. A worker may be assigned a role of either a map worker or a reduce worker.

Step 1. Split input

Figure 1. Split input into shards

The first step, and the key to massive parallelization in the next step, is to split the input into multiple pieces. Each piece is called a split, or shard. For M map workers, we want to have M shards, so that each worker will have something to work on. The number of workers is mostly a function of the amount of machines we have at our disposal.

The MapReduce library of the user program performs this split. The actual form of the split may be specific to the location and form of the data. MapReduce allows the use of custom readers to split a collection of inputs into shards, based on specific format of the files.

Step 2. Fork processes

Figure 2. Remotely execute worker processes

The next step is to create the master and the workers. The master is responsible for dispatching jobs to workers, keeping track of progress, and returning results. The master picks idle workers and assigns them either a map task or a reduce task. A map task works on a single shard of the original data. A reduce task works on intermediate data generated by the map tasks. In all, there will be M map tasks and R reduce tasks. The number of reduce tasks is the number of partitions defined by the user. A worker is sent a message by the master identifying the program (map or reduce) it has to load and the data it has to read.

Step 3. Map

Figure 3. Map task

Each map task reads from the input shard that is assigned to it. It parses the data and generates (key, value) pairs for data of interest. In parsing the input, the map function is likely to get rid of a lot of data that is of no interest. By having many map workers do this in parallel, we can linearly scale the performance of the task of extracting data.

Step 4: Map worker: Partition

Figure 4. Create intermediate files

The stream of (key, value) pairs that each worker generates is buffered in memory and periodically stored on the local disk of the map worker. This data is partitioned into R regions by a partitioning function.

The partitioning function is responsible for deciding which of the R reduce workers will work on a specific key. The default partitioning function is simply a hash of key modulo R but a user can replace this with a custom partition function if there is a need to have certain keys processed by a specific reduce worker.

Step 5: Reduce: Sort (Shuffle)

Figure 5. Sort and merge partitioned data

When all the map workers have completed their work, the master notifies the reduce workers to start working. The first thing a reduce worker needs to is to get the data that it needs to present to the user's reduce function. The reduce worker contacts every map worker via remote procedure calls to get the (key, value) data that was targeted for its partition. This data is then sorted by the keys. Sorting is needed since it will usually be the case that there are many occurrences of the same key and many keys will map to the same reduce worker (same partition). After sorting, all occurrences of the same key are grouped together so that it is easy to grab all the data that is associated with a single key.

This phase is sometimes called the shuffle phase.

Step 6: Reduce function

Figure 6. Reduce function writes output

With data sorted by keys, the user's Reduce function can now be called. The reduce worker calls the Reduce function once for each unique key. The function is passed two parameters: the key and the list of intermediate values that are associated with the key.

The Reduce function writes output sent to file.

Step 7: Done!

When all the reduce workers have completed execution, the master passes control back to the user program. Output of MapReduce is stored in the R output files that the R reduce workers created.

The big picture

Figure 7 illustrates the entire MapReduce process. The client library initializes the shards and creates map workers, reduce workers, and a master. Map workers are assigned a shard to process. If there are more shards than map workers, a map worker will be assigned another shard when it is done. Map workers invoke the user's Map function to parse the data and write intermediate (key, value) results onto their local disks. This intermediate data is partitioned into R partitions according to a partioning function. Each of R reduce workers contacts all of the map workers and gets the set of (key, value) intermediate data that was targeted to its partition. It then calls the user's Reduce function once for each unique key and gives it a list of all values that were generated for that key. The Reduce function writes its final output to a file that the user's program can access once MapReduce has completed.

Figure 7. MapReduce

Dealing with failure

The master pings each worker periodically. If no response is received within a certain time, the worker is marked as failed. Any map or reduce tasks that have been assigned to this worker are reset back to the inital state and rescheduled on other workers.

Locality

MapReduce is built on top of GFS, the Google File System. Input and output files are stored on GFS. The MapReduce workers run on GFS chunkservers. The MapReduce master attempts to schedule a map worker onto one of the machines that holds a copy of the input chunk that it needs for processing. Alternatively, MapReduce may read from or write to BigTable.

What is it good for and who uses it?

MapReduce is clearly not a general-purpose framework for all forms of parallel programming. Rather, it is designed specifically for problems that can be broken up into the the map-reduce paradigm. Perhaps surprisingly, there are a lot of data analysis tasks that fit nicely into this model. While MapReduce is heavily used within Google, it also found use in companies such as Yahoo, Facebook, and Amazon.

The original, and proprietary, implementation was done by Google. It is used internally for a large number of Google services. The Apache Hadoop project built a clone to specs defined by Google. Amazon, in turn, uses Hadoop MapReduce running on their EC2 (elastic cloud) computing-on-demand service to offer the Amazon Elastic MapReduce service.

Some problems it has been used for include:

Distributed grep (search for words)
Map: emit a line if it matches a given pattern
Reduce: just copy the intermediate data to the output
Count URL access frequency
Map: process logs of web page access; output
Reduce: add all values for the same URL
Reverse web-link graph
Map: output for each link to target in a page source
Reduce: concatenate the list of all source URLs associated with a target. Output
Inverted index
Map: parse document, emit pairs
Reduce: for each word, sort the corresponding document IDs; emits a pair. The set of all output pairs is an inverted index

References

Jeffrey Dean and Sanjay Ghemawat, MapReduce: Simplified Data Processing on Large Clusters, OSDI'04: Sixth Symposium on Operating System Design and Implementation, San Francisco, CA, December, 2004.
The introductory and definitive paper on MapReduce
Jerry Zhao, Jelena Pjesivac-Grbovic, MapReduce: The programming model and practice, SIGMETRICS'09 Tutorial, 2009.
Tutorial of the MapReduce programming model.
MapReduce.org,
Amazon Elastic MapReduce,
Amazon's MapReduce service
Google: MapReduce in a Week , Google Code University
MapReduce course, a part of 2008 Independent Activities Period at MIT
